Large Air Flow
High-strength stainless steel propeller with advanced fluid design that provides large air flow, low noise, and high efficiency.
High Efficiency
IP55 waterproof and dust-proof protection, F class insulation, ultra-efficient motor with 85% efficiency enables animal producers to save breeding costs and increase profits.
High Strength
Box housing and venturi nozzle are made of “X” gauge galvanized sheet-steel with 275g/㎡ zinc layer coating, which enables to withstand the harsh environment of the breeding sites.
Long Durability
Belt drive, adopt imported famous brand belt, made of neoprene composite materials and fiberglass cord core, that provides high strength, good wear resistance, high flexibility and high tensile resistance.
Good Airtightness
The shutter is automatically open and close by a centrifugal push-pull device, which ensures air tightness and prevents light transmittance.
Wide Application
Can be widely used in all kinds of livestock breeding, greenhouse, all kinds of warehouses and plant cooling.
Large Air Flow
High-strength stainless steel propeller with advanced fluid design that provides large air flow, low noise, and high efficiency.
High Efficiency
IP55 waterproof and dust-proof protection, F class insulation, ultra-efficient motor with 85% efficiency enables animal producers to save breeding costs and increase profits.
High Strength
Box housing and venturi nozzle are made of “X” gauge galvanized sheet-steel with 275g/㎡ zinc layer coating, which enables to withstand the harsh environment of the breeding sites.
Long Durability
Belt drive, adopt imported famous brand belt, made of neoprene composite materials and fiberglass cord core, that provides high strength, good wear resistance, high flexibility and high tensile resistance.
Good Airtightness
The shutter is automatically open and close by a centrifugal push-pull device, which ensures air tightness and prevents light transmittance.
Wide Application
Can be widely used in all kinds of livestock breeding, greenhouse, all kinds of warehouses and plant cooling.
型号|Model No. | QT915B2-077-00 | QT1270B2-081-00 | ||||
规格 |Diameter of blade (inch) | 36" | 50" | ||||
电机 | Motor | 电压 | Voltage (V) | 380 | 230 | 380 | 230 | |
频率 | Hertz (Hz) | 50 | 60 | 50 | 60 | ||
相数 | Phase | 3 | 3 | ||||
功率 | Power (KW) | 0.55 | 1.1 | ||||
输入电流 | Current @0Pa (A) | 1.7 | 3 | ||||
性能参数 | Performance | 风量 | Airflow (m^3/hr.) | 0pa | 18400 | 38700 | ||
-25pa | 16080 | 35500 | ||||
-50pa | 12750 | 30500 | ||||
能效比 | Efficiency ( CMH/Watt) | 23.3 | 21.8 | ||||
特征 | Features | 驱动方式 | Drive | 皮带传动|Belt driven | ||||
风叶 | Propeller | 6片铝叶 | 6-Aluminum | |||||
外形尺寸 | Dimension (mm) | A01 | 915 | 1270 | |||
A02 | 1000 | 1380 | ||||
A03 | 1000 | 1380 | ||||
A04 | 450 | 450 | ||||
A05 | 500 | 500 | ||||
洞口尺寸|Dimmersion of opening (mm) | 1020×1020 | 1440×1440 |
型号|Model No. | QT915B2-077-00 | QT1270B2-081-00 | ||||
规格 |Diameter of blade (inch) | 36" | 50" | ||||
电机 | Motor | 电压 | Voltage (V) | 380 | 230 | 380 | 230 | |
频率 | Hertz (Hz) | 50 | 60 | 50 | 60 | ||
相数 | Phase | 3 | 3 | ||||
功率 | Power (KW) | 0.55 | 1.1 | ||||
输入电流 | Current @0Pa (A) | 1.7 | 3 | ||||
性能参数 | Performance | 风量 | Airflow (m^3/hr.) | 0pa | 18400 | 38700 | ||
-25pa | 16080 | 35500 | ||||
-50pa | 12750 | 30500 | ||||
能效比 | Efficiency ( CMH/Watt) | 23.3 | 21.8 | ||||
特征 | Features | 驱动方式 | Drive | 皮带传动|Belt driven | ||||
风叶 | Propeller | 6片铝叶 | 6-Aluminum | |||||
外形尺寸 | Dimension (mm) | A01 | 915 | 1270 | |||
A02 | 1000 | 1380 | ||||
A03 | 1000 | 1380 | ||||
A04 | 450 | 450 | ||||
A05 | 500 | 500 | ||||
洞口尺寸|Dimmersion of opening (mm) | 1020×1020 | 1440×1440 |
